I/O ports and slots
24 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 type 10BASE-T, IEEE 802.3u type 100BASE-TX, IEEE 802.3ab type 1000BASE-T)
Duplex: 10BASE-T/100BASE-TX: Half or full
1000BASE-T: Full only
4 fixed GbE SFP ports
Additional ports and slots
1 Dual-Personality (RJ-45 or USB Micro-B) serial console port
Memory and processor
ARM9E @ 800 MHz, 128MB flash
Packet buffer size: 1.5MB dynamically allocated, 256MB DDR3 DIMM
Mounting and enclosure
Mounts in an EIA-Standard 19-inch telco rack or equipment cabinet (Rack-Mounting kit available)
Horizontal surface mounting
Wall mounting
Management
IMC
CLI
Web browser
Configuration menu
Out-of-Band management (Serial RS-232C or Micro-USB)
IEEE 802.3 Ethernet MIB
Repeater MIB
Ethernet interface MIB
